ATTACKInquiry Only
RX-W2500
Long-Endurance Attack UAV
Type B delta-wing fixed-wing attack platform delivering 12 hours of sustained endurance at 20 kg payload. 550cc piston engine with 37 kW output, 2,000 km operational range, and advanced GPS/SINS/AHRS navigation with centimeter-level differential positioning.
12h
Endurance
2,000km
Max Range
50kg
Max Payload
Key Capabilities
- 12 h endurance with 20 kg payload on 37 kW piston engine
- 2,000 km operational range — strategic deep-strike capable
- Delta-wing carbon fiber airframe — reduced drag, high L/D ratio
- One-touch autonomous takeoff, cruise & landing
- 1.4 GHz OFDM data link — 10 km base, 30 km extended
Product Manual
Request Datasheet via ContactTechnical Specifications
Airframe
Aircraft Length3,200 mm
Wingspan2,500 mm
MTOW180–220 kg
Standard Payload35–50 kg
Flight Performance
Cruise Speed180–220 km/h
Endurance12 h (@ 20 kg load)
Max Range2,000 km
Launch MethodRATO (rocket-assisted)
Propulsion
Engine550cc piston, 4-cyl. opposed, 2-stroke
Rated Power37 kW
ConfigurationTail-push propeller
Data Link
Frequency1.37–1.45 GHz (1.4 GHz band)
Base Range10 km
Extended Range30 km (extended)
